TP-Link TL-WR841N 300Mbps Wi-Fi Router

স্পেসিফিকেশন

Standards and Protocols

Wi-Fi 4, IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds

N300, 2.4 GHz: 300 Mbps (802.11n)

WiFi Range

2 Bedroom Houses, 2× Fixed Antennas

WiFi Capacity

Legacy

Working Modes

Router Mode, Access Point Mode, Range Extender Mode, WISP Mode

Network Security

SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway

Guest Network

1× 2.4 GHz Guest Network

WiFi Encryption

WEP, WPA, WPA2, WPA/WPA2-Enterprise (802.1x)

Processor

Single-Core CPU

Ethernet Ports

1× 10/100 Mbps WAN Port, 4× 10/100 Mbps LAN Ports

Power

9 V ⎓ 0.6 A

Buttons

Reset Button

Protocols

IPv4, IPv6

Parental Controls

URL Filtering, Time Controls

WAN Types

Dynamic IP, Static IP, PPPoE, PPTP, L2TP

Quality of Service

QoS by Device

NAT Forwarding

VIrtual Server, Port Forwarding, Port Triggering, DMZ, UPnP

IPTV

IGMP Proxy, IGMP Snooping

DHCP

Address Reservation, DHCP Client List, Server

DDNS

NO-IP, Comex, DynDNS

Management Features

Tether App, Webpage, Check Web Emulator>

Network Services Enabled by Default

Web Server, Manage and configure device through web (HTTP/HTTPS), • Port: 80/443 Protocol: TCP, DHCP Server, IP address assignment (DHCP), • Port: 67 Protocol: UDP

System Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser, Cable or DSL Modem (if needed), Subscription with an internet service provider (for internet access)

Certifications

FCC, CE

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉), Storage Temperature: -40℃~70℃ (-40℉ ~158℉), Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing

WiFi Transmission Power

CE:, <20dBm(2.4GHz), FCC:, <30dBm

WiFi Reception Sensitivity

270M: -70dBm@10% PER, 130M: -74dBm@10% PER, 108M: -74dBm@10% PER, 54M: -77dBm@10% PER, 11M: -87dBm@8% PER, 6M: -90dBm@10% PER

Dimensions (W×D×H)

6.9 × 4.6 × 1.3 in, (173 × 118 × 33mm)

Package Content

Wi-Fi Router TL-WR841N, Power Adapter, RJ45 Ethernet Cable, Quick Installation Guide
